Hoffman Hoffman LWHD1616
Hoffman LWHD1616
Kirby Risk #: 1870038
UPC: 78351049910, 783510499105, 00783510499105
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Hoffman
Description
Industry Description
Deep-Hinged Window, fits 166x160mm, Polycarbonate
Modified Industry Description
DEEP WINDOW, FITS166X160
AD Description
Hoffman INLINE™ LWHD1616 C3 Deep Hinged Window Kit, 5.47 in H x 4.43 in W, 6.54 in H x 6.3 in W x 1.63 in D, For Use With INLINE™ 166 x 160 mm Operator Interface Enclosures, Polycarbonate, Black, Polyester Powder Painted
Vendor Description
Clear molded polycarbonate window has a 31.8-mm (1.25-in.) clear space between enclosure front opening and window surface. Space also accommodates equipment mounted on optional front plate. Window kit is hinged on left side with a 140-degree door opening and a quarter-turn slotted latch. Includes mounting hardware for window and optional front plate. Die-cast backing plate has a black polyester powder finish. This kit can be used as an accessory window kit on other HOFFMAN enclosures.
Specifications
| Application |
Clear molded polycarbonate window has a 31.8-mm (1.25-in.) clear space between enclosure front opening and window surface. Space also accommodates equipment mounted on optional front plate. Window kit is hinged on left side with a 140-degree door opening
|
|---|---|
| Brand Name |
Hoffman
|
| Color |
Black
|
| Country of Origin |
US
|
| Material |
Polycarbonate
|
| Series |
C3 Series
|
| Size |
fits 166X160mm
|
| Sub_Brand |
Hoffman
|
| Type |
Deep Hinged
|
