Hubbell Hubbell HBL1298
Hubbell HBL1298
Kirby Risk #: 1810051
UPC: 10783585016945, 00783585016948, 78358501694
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Hubbell
Description
Industry Description
Hubbell Wiring Device Kellems, Switches and Lighting Controls, PilotLighted Industrial Grade, PresSwitch, General Purpose AC, Three Way, 20A120/277V AC, Screw Terminals, Red
Modified Industry Description
RED 20A120V 3W PILOT LGT PRESS
AD Description
Wiring Device-Kellems PresSwitch® HBL1298 3-Way General Purpose Heavy Duty Pilot Light Standard Pushbutton Switch, 120 VAC, 20 A, 2400 W Power Rating, 2-Position/SPDT Contact
Specifications
| Action |
Snap
|
|---|---|
| Actuator |
Push Button
|
| Amperage Rating |
20
|
| Application |
Heavy Duty Industrial
|
| Brand Name |
Hubbell
|
| Color |
Red
|
| Connection |
Terminal Screws
|
| Contact_Configuration |
Two Position
|
| Country of Origin |
US
|
| Environmental_Conditions |
Indoor Dry unless Protected by Additional Means
|
| Indicator |
Light On with Load On
|
| Mounting |
Mounting Screws
|
| Number_Of_Poles |
1
|
| Operating_Cycles |
10k
|
| Operating_Temperature |
Maximum continuous 75°C and minimum -40°C without Impact
|
| Size |
3.28 X 1.5 X 1.45
|
| Special Features |
|
| Standard |
Fed. Spec. W-S-896
|
| Sub_Brand |
Hubbell Wiring Device-Kellems
|
| Type |
PresSwitches
|
| Voltage Rating |
120
|
| Wattage |
2,400
|
