Thomas & Betts Thomas & Betts BTC4102
Thomas & Betts BTC4102
Kirby Risk #: 1784737
UPC: 78378661136, 783786611362, 30783786611363
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Thomas & Betts
Description
Industry Description
Type BTC - Copper Single-Conductor, One-Hole Mount (Offset-Tang), Conductor Range 2 Str-4/0 Str, Length 2-9/16 Inches, Width 1 Inch, Height 1-61/64 Inches, 11/32 Inch Bolt Hole
Modified Industry Description
OFFSET CU MECH CONNECTOR
AD Description
Blackburn® BTC4102 Type BTC Mechanical Connector, 2 to 4/0 AWG Stranded Copper Conductor, 11/32 in Stud, 1 Bolt Hole, Copper
Vendor Description
Blackburn® cast, forged or formed mechanical connections, produced in economical copper and dual-rated aluminum, provide unequaled variety with a large variety of UL and CSA certified solutions for your electrical interface needs.
Specifications
| Brand Name |
Thomas & Betts
|
|---|---|
| Conductor_Range_Main_Primary |
2 Str.-4/0 Str.
|
| Conductor Size |
2 to 4/0
|
| Country of Origin |
MX
|
| Material |
Copper
|
| Package_Quantity |
5
|
| Special Features |
|
| Standard |
UL E9809
|
| Stud_Size |
11/32
|
| Sub_Brand |
Blackburn
|
| Type |
Type BTC
|
