Siemens Siemens GF324NR


Description

Industry Description

Siemens Low Voltage Circuit Protection General Duty Safety Switch. 3-Pole 3-Fuse and solid neutral Fused in a type 3R enclosure (outdoor). Rated 240VAC (200A).Horse power (Std, Time delay) fused 1-PH 2-W (15, - ), 3-PH 3-W (25, 60), 250VDC (40). Special features service entrance labeled .

Modified Industry Description

200A 240V - FUSED NEMA 3R SAFETY SWITCH, 3 POLE, GENERAL DUTY

AD Description

Siemens GF324NR Enclosed Fused General Duty Low Voltage Safety Switch With Neutral, 240 VAC, 200 A, 15 hp, 40 hp, TPST Contact, 3 Poles

Specifications

Action
SINGLE THROW
Actuator
SINGLETHROW
Amperage Rating
200
Brand Name
Siemens
Connection
MECHANICALLUGS
Country of Origin
MX
Enclosure
TYPE 3R
Environmental_Conditions
Outdoor
Frequency_Rating
60
FuseClassProvision
Fusible
Insulation
None
Material
304 Stainless Steel
Mounting
2 OR 3 POINT MOUNTING HOLES
NEMA_Configuration
3R
Number_Of_Poles
3
Number_Of_Wires
3
Operating_Cycles
8000
Operating_Temperature
(-20F-120F) AMBIENT TEMPERATURE
Phase
1/3
Poles
3
Special Features

  • A unique enclosure design that adds rigidity and strength, its rolled edge prevents cuts and scrapes to conductors and to installers hands
  • Cover interlock
  • Generous wiring gutters that meet or exceed NEC® wire bending space requirements
  • Handle and cover padlocking provisions
  • Highly visible red handle grip
  • Informative door labeling which includes replacement parts list
  • Positive 2 or 3-point mounting
  • Quick-make, quick-break operating mechanism that ensures positive operation
  • Side hinged door that opens 180 deg for easier wiring
  • Tangential knockouts through 600 A for easy conduit lineup
  • Visible blade, double break switching action
  • Without insulation
Standard
UL
Sub_Brand
Siemens
Type
Enclosed Fused Low Voltage
Voltage Rating
240
Wattage
4
