Microswitch Microswitch BAF1-2RN2-LH


Description

Modified Industry Description

SPDT ROLLER LEVER ACTION LIMIT SWITCH

AD Description

Honeywell MICRO SWITCH™ BAF1-2RN2-LH Enclosed Limit Switch, 125/250/480 VAC/125/250 VDC, 0.25 to 20 A, Top Roller Arm Lever Actuator, 1NC-1NO SPDT, 1 Pole

Vendor Description

MICRO SWITCH BAF/DTF high capacity enclosed switches offer elastomer boot on sealed actuator verions that protects the actuating mechanism and the internal basic switch from contaminants. There is a seal gasket between the cover plate and the enclosures on all versions. The cover plate is removed for ease of wiring and switch replacement without demounting the switch. The actuator position is designated right or left, when looking at the nameplate.

Specifications

Action
Snap
Actuator
Top Roller Arm Lever
Amperage Rating
0.25 to 20
Brand Name
Microswitch
Contact_Configuration
1NC-1NO SPDT
Material
Die Cast Aluminum
Number_Of_Poles
1
Operating_Temperature
-32 to 71
Package_Quantity
1
Special Features

  • 0.51 mm (0.020 in) maximum differential travel
  • 2.22 N (0.50 lb) minimum release force
  • 20 A inductive/0.5 A resistive/0.25 A resistive current
  • 5.56 mm (0.219 in) maximum pretravel
  • 6.35 mm (0.25 in) minimum over travel
  • 8.90 N (2.0 lb) maximum operating force
  • Cast aluminum housing with three-hole mounting
  • Cover seal, captive cover screws
  • Industrial sealed
  • Momentary or maintained contact
  • Right or left-handed (sealed or unsealed) actuators
  • With seal boot on plunger, lever field adjustable 360 deg horizontally and 225 deg vertically, left hand actuator position
Type
Enclosed
Voltage Rating
125/250/480 VAC/125/250 VDC
