3M 3M 10001
3M 10001
Kirby Risk #: 530756
UPC: 05400712717, 054007127178, 00054007127178
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: 3M
Description
Industry Description
They are designed to connect copper conductors. Each connector is electro-tin plated to resist electrolytic corrosion. They are installed using standard industry tooling. Chamfered ends and an integral center cable stop ensure simplicity and ease of conductor insertion.
Modified Industry Description
# 6 SPLICE
AD Description
3M™ Scotchlok™ 054007-12717 10000 Non-Insulated Standard Barrel Compression Connector, 6 AWG Stranded Copper Conductor, 1-3/4 in L, Copper
Vendor Description
3M™ Scotchlok™ connectors and tools are engineered to work together to achieve consistently superior performance in the field.
Specifications
| Brand Name |
3M
|
|---|---|
| Color |
Blue
|
| Conductor Type |
Stranded Copper
|
| Conductor Size |
6
|
| Country of Origin |
CL
|
| Finish |
Electro Tin Plated
|
| Label_Description |
3M(TM) SCOTCHLOK(TM) COPPER STANDARD BARREL CONNECTOR 10001 , BLUE, 6 AWG, 50 PER CASE
|
| Material |
Copper
|
| Package_Quantity |
50
|
| Special Features |
|
| Standard |
UL Listed
|
| Sub_Brand |
3M
|
| Temperature_Rating |
105
|
| Type |
Non-Insulated Standard Barrel
|
| Voltage Rating |
35
|
