Hubbell Hubbell HBL5352BK


Description

Industry Description

Hubbell Wiring Device Kellems, Straight Blade Devices, Receptacles,Duplex, Commercial/Industrial Grade, 2-Pole 3-Wire Grounding, 20A 125V,5-20R, Black, Single Pack

Modified Industry Description

20A 125V RECPT BLACK

AD Description

Wiring Device-Kellems HBL® HBL5352BK Compact Duplex Straight Blade Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, Black

Specifications

Amperage Rating
20
Application
Extra Heavy Duty Compact
Brand Name
Hubbell
Color
Black
Connection
Back and Side Wired
Conductor Size
#14 AWG to #12 AWG
Country of Origin
US
Dielectric_Strength
Withstands 2,000V minimum
Environmental_Conditions
Indoor Dry unless Protected by Additional Means
Grade
Specification
Material
Thermoplastic/Composite
Mounting
Screw Mount
NEMA_Configuration
5-20R
NEMA_Rating
5-20R
Number_Of_Poles
2-Pole
Number_Of_Wires
3-Wire Grounding
Phase
Single
Size
Standard Sized Product
Special_Features

  • 12 to 10 AWG stranded or solid copper wire only
  • Brass contacts, mounting strap and terminal screws, plated brass wire clamp, stainless steel automatic self-grounding clip, steel-zinc plated mounting screws
  • Certified for current interrupting at full rated current
  • HBL® extra heavy duty compact receptacles
  • Nylon face and RTB base
  • Slender/compact design
  • Terminals identified in accordance with UL 498 and CSA
  • Triple wipe contacts
  • Withstands 2000 VAC minimum dielectric voltage

Standard
NEMA WD1 and WD5, UL 498
Sub_Brand
Hubbell Wiring Device-Kellems
Type
Duplex
Voltage Rating
125
Wattage
2000Watts
