Hubbell Hubbell HBL2547
Hubbell HBL2547
Kirby Risk #: 497560
UPC: 78358523590, 783585235905, 00783585235905
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Hubbell
Description
Industry Description
Hubbell Wiring Device Kellems, Locking Devices, TwistLock, Elastogrip,Female Connector Body, 15A 125V, 2-Pole 3-Wire Grounding, L5-15R, ScrewTerminal, Yellow, DustTight Housing
Modified Industry Description
15A 125V - LOCKING FEMALE CONNECTOR, 2 POLE, 3 WIRE
AD Description
Hubbell® Twist-Lock® Elastogrip® HBL2547 Grounding Connector, 125 VAC, 15 A, 2 Poles, 3 Wires, Yellow
Specifications
| Amperage Rating |
15
|
|---|---|
| Application |
Heavy Duty Industrial
|
| Brand Name |
Hubbell
|
| Color |
Yellow
|
| Conductor Range |
#14AWG - #12AWG
|
| Connection |
Pressure Screw Terminal
|
| Country of Origin |
PR
|
| Enclosure |
IP20
|
| Environmental_Conditions |
Water Tight
|
| Grade |
Industrial
|
| Material |
Elastomer
|
| Mounting |
Cord Mounted
|
| NEMA_Configuration |
L5-15R
|
| NEMA_Rating |
L5-15R
|
| Number Of Conductors |
2-Wire Non-Grounding
|
| Number_Of_Poles |
2
|
| Number_Of_Wires |
3
|
| Poles |
2
|
| Size |
Standard
|
| Special Features |
|
| Standard |
NEMA WD1 and WD5, UL498
|
| Sub_Brand |
Hubbell Wiring Device-Kellems
|
| Temperature_Rating |
-40 to 75
|
| Type |
Grounding
|
| Voltage Rating |
125
|
