Hubbell Hubbell HBLDS6AC
Hubbell HBLDS6AC
Kirby Risk #: 490228
UPC: 78358543073, 783585430737, 00783585430737
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Hubbell
Description
Industry Description
Hubbell Wiring Device Kellems, Switches and Lighting Controls,Industrial Grade, Disconnect Switches, Unfused Switch, Three Pole, 60A600V AC, Screw Terminals, Gray, NEMA 4XEnclosure, With Aux Contact
Modified Industry Description
60A 600V - 3 POLE UNFUSED DISCONNECT SWITCH W/ AUXILIARY CONTACT
AD Description
Wiring Device-Kellems Circuit-Lock® HBLDS6AC Non-Fusible Enclosed Disconnect Switch With Auxiliary Contacts, 600 VAC, 60 A, 50 hp, 2-Position Contact, 3 Poles
Specifications
| Action |
Snap
|
|---|---|
| Actuator |
Lever
|
| Amperage Rating |
60
|
| Application |
Extra Heavy Duty Industrial
|
| Brand Name |
Hubbell
|
| Connection |
Terminal Screws
|
| Contact_Configuration |
Two Position
|
| Country of Origin |
PL
|
| Enclosure |
NEMA 4X
|
| Environmental_Conditions |
NEMA 4X
|
| Frequency_Rating |
60
|
| Material |
Composite
|
| Mounting |
Mounting Feet
|
| Number_Of_Poles |
3
|
| Operating_Cycles |
6k
|
| Operating_Temperature |
Max Continuous- 67 Degrees C, Minimum- -40 Without Impact
|
| Phase |
3
|
| Size |
Standard Sized
|
| Special Features |
|
| Standard |
UL 746C
|
| Sub_Brand |
Hubbell Wiring Device-Kellems
|
| Type |
Non-Fusible
|
| Voltage Rating |
600
|
| Width_2 |
8.9000
|
