Hubbell Hubbell HBL8666V


Description

Industry Description

Hubbell Wiring Device Kellems, Straight Blade Devices, Male Plug, ValiseSeries, HospitalGrade, Straight, 2-Pole 3-Wire Grounding, 15A 250V, 6-15P, White, Single Pack

Modified Industry Description

15A 250V MALE WHITE HOSPITAL VALISE

AD Description

Wiring Device-Kellems Valise® HBL8666V Grounding Standard Straight Blade Plug, 250 VAC, 15 A, 2 Poles, 3 Wires, White

Vendor Description

Have it all with the Valise® line of plugs and connector bodies from Hubbell, Inc. With Valise® devices, OEMs and Contractors will get the speed, ease and economy they want While being able to offer their customers and end users excellence in performance durability and reliability.

Specifications

Amperage Rating
15
Application
Hospital Grade
Brand Name
Hubbell
Color
White
Connection
Terminal Screws
Conductor Size
#18 AWG to #12 AWG
Cord_Type
All Portable
Country of Origin
PR
Enclosure
IP20
Environmental_Conditions
Indoor Dry unless Protected by Additional Means
Grade
Hospital
Material
Composite
Mounting
Cord Mounted
NEMA_Rating
NEMA 6-15P
Number_Of_Poles
2
Number_Of_Wires
3
Phase
1
Size
Standard Sized
Special Features

  • 18 to 12 AWG solid or stranded copper conductor terminal accommodation
  • Certified for current interrupting at full rated current
  • Cord mounted
  • Corrosion resistant
  • Eight specially designed load bearing locking lugs insure a positive fit as the blade holder and sides are closed
  • Grounding plug
  • Maximum 30 deg C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 75% temperature rise
  • Noryl (polyphenylene oxide) cord clamp, brass contact blade and ground contact blade, stainless steel terminal and ground screw
  • Nylon webs are provided to make wiring quick and easy by joining the three sections together during assembly
  • Powerful cord grips prevent conductor slippage and strain on wiring terminals
  • Removable cord inserts
  • Totally insulated impact and crush resistant nylon body
  • Two captive multiple drive assembly screws
  • Unique, patented clamp type terminals provide superior electrical connection by bundling conductor strands when clamps are tightened
  • Withstands 2000 VAC dielectric voltage
Standard
NEMA WD1 and WD5, UL498
Sub_Brand
Hubbell Wiring Device-Kellems
Temperature_Rating
-40 to 75
Type
Grounding Standard
Voltage Rating
250
Wattage
3,750
