Thomas & Betts Thomas & Betts CTL250-12


Description

Industry Description

Copper One-Hole Lug, Short Barrel, Max 35kV, 250 kcmil Wire, 1/2 Bolt Size, Tin Plated, Die Color Code Yellow

Modified Industry Description

1/2 IN 1 HOLE YELLOW COPPER LUG, 250 MCM, SHORT BARREL

AD Description

Blackburn® CTL250-12 1-Hole Compression Lug, 250 kcmil Copper/Stranded Conductor, 1/2 in Stud, Copper

Vendor Description

Blackburn® is a complete and reliable line of overhead, grounding, mechanical and compression connectors that respond to a broad range of construction needs.

Specifications

Brand Name
Thomas & Betts
Cable_Size
250 kcmil
Color
Yellow
Conductor Material
Copper
Conductor Size
250
Country of Origin
MX
Finish
Tin Plated
Material
Copper
Number_Of_Holes
1
Package_Quantity
10
Special Features

  • Can be used for medium voltage application up to 35 kV provided proper insulation techniques are used
  • Color coded for matching die identification
  • For use with copper conductor AWG, stranded, flexible cable, welding cable and portable cord
  • Made of high conductivity seamless copper tubing
  • Short barrel connectors designed for regular duty applications
  • Specially chamfered barrel for ease of installation
  • Tin plated for corrosion-resistance
Standard
UL E9809
Stud_Size
1/2
Sub_Brand
Blackburn
Tongue_Angle
Straight
Type
1-Hole
Voltage Rating
35
