ABB (T&B) Thomas & Betts BTC3104


Description

Industry Description

Type BTC - Copper Single-Conductor, One-Hole Mount (Offset-Tang), Conductor Range 4 Str-3/0 Str, Length 2-3/6 Inches, Width 3/4 Inch, Height 1-9/16 Inches, 13/32 Inch Bolt Hole

Modified Industry Description

OFFSET CU MECH CONNECTOR

AD Description

Blackburn® BTC3104 Type BTC Mechanical Connector, 4 to 3/0 AWG Stranded Copper Conductor, 13/32 in Stud, 1 Bolt Hole, Copper

Vendor Description

Blackburn® cast, forged or formed mechanical connections, produced in economical copper and dual-rated aluminum, provide unequaled variety with a large variety of UL and CSA certified solutions for your electrical interface needs.

Specifications

Brand Name
Thomas & Betts
Conductor_Range_Main_Primary
4 Str.-3/0 Str.
Conductor Size
4 to 3/0
Country of Origin
MX
Material
Copper
Package_Quantity
5
Special_Features

  • 1 stud of 13/32 in
  • Made of electrolytic seamless copper with steel screw
  • Uniquely designed pressure bar and notched v-bottom collar provide vise-like grip between conductor and terminal

Standard
UL E9809
Stud_Size
13/32
Sub_Brand
Blackburn
Type
Type BTC
