Cooper Wiring Cooper Wiring AH420R7W

Name: Cooper Wiring AH420R7W
Brand: Cooper Wiring
SKU: 3262685
Price: 199.50 USD
Availability: InStock

Cooper Wiring AH420R7W

Kirby Risk #: 3262685

UPC: 03266473350, 032664733505, 00032664733505

Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)

Brand: Cooper Wiring

Description

Industry Description

Recp Pin&Sleeve 20A 480V 3PH 3P4W WT RD 4733505

AD Description

Crouse-Hinds Arrow Hart® AH420R7W 3-Phase Watertight Pin and Sleeve Receptacle, 480 VAC, 20 A, 3 Poles, 4 Wires, Red

Amperage Rating	20
Application	IEC 309 Products
Color	Blue/Gray
Connection	Pin & Sleeve
Country of Origin	CN
Dimensions	3.7500 X 3.4300 X 3.1250
Environmental_Conditions	IP67 & IP69k
Insulation	Nylon PA6-GF30FR (17)
Length1	3.7500
Material	Nylon
Mounting	Flange
Number_Of_Poles	3
Phase	3
Size	4.875 X 4.313 X 4.125
Special Features	Impact resistant thermoplastic cable Individual silicone sealing grommets with cord diameter range makes for faster, easier assembly Inlet and receptacle mounting footprint and blind holes provide interchangeability with major brands Nickel plated pins and contacts offer long-life corrosion protection Nylon face insulation Rugged materials selected for use in wet locations, provides corrosion resistance Spring loaded self-closing cap with silicone rubber gasket protects contacts when not in use Standard mounting footprints and blind holes provide interchangeability with major brands Watertight cap meets IP67 and IP69K protection standards
Standard	IEC, UL, CSA
Sub_Brand	ArrowHart Series
Temperature_Rating	Max. 30°C (86°F) after 50 cycles of overload @150% of rated current
Type	Receptacle
Voltage Rating	3Ø 480V/AC
