Cooper Wiring Cooper Wiring 6252W-BU


Description

Industry Description

Recp Deco Dup 15A 125V 2P3W B/Swire WH 4584039

AD Description

EATON Arrow Hart™ Eaton Wiring Devices 6252W-BU Decorator Duplex Straight Blade Receptacle, 125 VAC, 15 A, 2 Poles, 3 Wires, White

Vendor Description

Commercial specification grade straight blade receptacles - decorator 15 A, 125 VAC, NEMA 5-15R. engineered for safe, reliable performance, these UL 498 and Federal Specification W-C-596 listed devices provide maximum durability in a wide variety of applications while providing installation efficiency to help finish the job on time.

Specifications

Application
NON-RESI RECEPTACLE
Country of Origin
US
Dimensions
1.3200 X 0.8400 X 4.1900
Length1
1.3200
Special Features

  • 0.035 in galvanized steel, wraparound yoke mounting strap for superior assembly security, extra length/width helps reach large panel cutouts for code compliance
  • 0.046 in thick galvanized steel strap, phosphor bronze staple auto ground, 0.03 in thick 3-leaf brass line contacts, riveted ground contact
  • 14 to 10 AWG wire terminal
  • Automatic grounding system eliminates need for bonding jumper in grounded metal enclosure, provides redundant measure of ground continuity where jumper used
  • Commercial grade duplex receptacles are challenged on a daily basis to provide a consistent, reliable means of connectivity in a wide variety of environments
  • Durable impact and chemical resistant nylon face is virtually unbreakable
  • Durable impact and chemical-resistant nylon face is virtually unbreakable (excluding 6252 and 6352)
  • Excellent plug blade retention provided by triple wipe 0.032 in (0.81mm) triple wipe brass line contacts and 0.05 in (1.27mm) brass ground
  • Extra long and extra wide mounting straps
  • Flush mounting
  • Full-rated current interrupting
  • Maximum 30 deg C after 250 cycles of overload at 200% of rated current temperature rise
  • Meets UL 94 requirements, V2 rated
  • NO 8-32 Steel, brass plated hot, neutral screw nickel plated terminal screw, NO 8-32 steel (green) ground screw
  • Nylon face and PVC base
  • Nylon face, PVC base
  • Sturdy, compact design meets the demands of commercial spec grade performance
  • Terminal accommodation of NO 14 to 10 AWG
  • Terminal screws are backed out and ready to wire
  • Terminal screws are backed out and ready-to wire
  • Terminals accept up to #10 solid or stranded wire
  • Terminals accept up to 10 AWG solid or stranded wire
  • The applications vary greatly by environment, and provide challenges from impact and chemical resistance to environmental extremes such as heat and moisture
  • The breadth of the arrow hart straight blade receptacle line provides solutions for all environments and applications
  • Withstands 2000V per UL 498 dielectric voltage
Standard
Federal Specification Classification 6233 01,cULus Listed,RoHS Compliant,NAFTA
Sub_Brand
Eaton Wiring Devices
Type
Commercial
