Siemens Siemens 3UG4501-1AW30


Description

Industry Description

Analog monitoring relay fill level monitoring resistance monitoring from 2 to 200 kohm 0vershoot and undershoot 24 to 240 V AC/DC 50 to 60 HZ DC and AC 2-step or 1-step control tripping delay 0.5 to 10 s 1 change-over contact screw terminal successor product for 3ug3501

Modified Industry Description

LIQUID LEVEL MONITOR, 5-100

AD Description

SIRIUS 3UG4501-1AW30 3UG Monitoring Relay, 120 VAC, LED Display, 92 mm L x 22.5 mm W x 91 mm D

Specifications

Application
Single point and two point level monitoring
Class
N75
Connection
screw-type terminals
Country of Origin
CZ
Enclosure
IP20
Environmental_Conditions
80 -40 C
Length1
92
Mounting
screw and snap-on mounting any
Operating_Temperature
60 -25 C
Series
3UG
Special Features

  • 1 A measuring electrode current maximum
  • 15 VAC measuring electrode voltage maximum
  • 2 to 200 kOhm adjustable response value impedance
  • 2-point or 1-point control
  • 3 A at 24 VAC/3 A at 250 VAC AC-15, 1 A at 24 VAC/0.2 A at 125 VAC/0.1 A at 250 VAC DC-13 contact rating
  • Analog monitoring relay fill level monitoring
  • Analog monitoring relay fill level monitoring resistance monitoring from 2 to 200 kOhm overshoot and undershoot
  • Control tripping delayed 0.5 to 10 sec
  • Customary screw and spring-type terminals for quick and reliable wiring
  • Device replacement without renewed wiring thanks to removable terminals
  • Fast commissioning thanks to menu guided parameterization and actual value display for limit value determination
  • Parameterizable monitoring functions, delay times, reset behavior
  • Rapid diagnostics thanks to unambiguous error messages on the display
  • Reduced space requirement in the control cabinet thanks to a consistent width of 22.5 mm
  • Reduced stock keeping thanks to minimized variance and large measuring ranges
  • Reliable system diagnostics thanks to actual value display and connectable fault memory
  • Wide voltage power supply units for global applicability
Sub_Brand
Siemens
Type
3UG monitoring relays
Voltage Rating
120
