Crouse-Hinds Crouse-Hinds FSQC3320


Description

Industry Description

30A 2W3P 2P SWITCH DF INTERLOCK RECEPTACLE SPDR THRUFEED HUBS 1

Modified Industry Description

30A 2W3P 2P SWT DF INTRLCK RCPT

AD Description

Crouse-Hinds Arktite® FSQC3320 1/3-Phase Explosionproof Dead Front Interlocked Receptacle With Spring Door, 120/240/480/600 VAC, 30 A, 3 Poles, 2 Wires

Specifications

Amperage Rating
30
Application
Portable Electrical Equipment Such as Hand Lamps, Lighting Systems, Power Tools, Conveyors
Country of Origin
MX
Dimensions
10 in L x 5-3/4 in W x 4-3/4 in H
Horsepower
7-1/2
Insulation
Krydon
Length1
4.7500
Material
Copper Free Aluminum
NEMA_Rating
NEMA 3/7B/7C/7D/9F/9G/12
Number_Of_Poles
3
Phase
1-3/2014
Series
FSQC
Size
10 In Length X 5.75 In Width
Special Features

  • 1 in hub
  • Brass contact, copper free aluminum enclosure, cover and spring door
  • Compatible with Arktite® APJ aluminum and NPJ Krydon® plugs
  • Cover cannot be removed when switch is ON
  • Explosionproof, dust-ignitionproof, rain tight
  • Extra pole grounding style
  • Indoors or outdoors in hydrogen areas of process industries, missile bases where hydrogen fuel is used and gas manufacturing plants
  • Krydon® insulator
  • Plug cannot be withdrawn under load
  • Smallest mounting footprint for interlock
  • Switch cannot be turned ON until plug is fully inserted and rotated
  • To supply power to portable electrical equipment such as motor-generator sets, compressors, heating and cooling units, lighting systems, conveyors and similar equipment
Standard
UL 1010, CSA C22.2, CUL C22.2
Sub_Brand
Eaton Crouse-Hinds
Type
1/3-Phase Explosionproof
Voltage Rating
120/240/480/600
