Siemens Siemens E1FED22B100SN
Siemens E1FED22B100SN
Kirby Risk #: 3133509
UPC: 78364320255, 783643202559, 00783643202559
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Siemens
Description
Industry Description
SIEMENS LOW VOLTAGE ENCLOSED SENTRON MOLDED CASE CIRCUIT BREAKER (ASSEMBLED) WITH THERMAL - MAGNETIC TRIP UNIT. 100A 2-POLE 240V STANDARD 40 DEG C BREAKER ED FRAME WITH STANDARD BREAKING CAPACITY (ED22B100). NON-INTERCHANGEABLE TRIP UNIT. NEMA TYPE 1 ENLCOSURE FLUSH MOUNTED (E2N1F) WITH NEUTRAL (W53045). INCLUDES LINEAND LOAD SIDE LUGS (LN1E100) WIRE RANGE 10 - 1/0AWG (CU/AL). ACCESSORIES INCLUDED (S01ED60) ENCLOSURE DIMENSIONS (W x H x D) IN 8.50 x 17.50 x 5.06.
Modified Industry Description
BREAKER ENC1F 2P 100A 240V 10KA ST
AD Description
Sentron™ E1FED22B100SN Type ED2 Low Voltage Molded Case Circuit Breaker, 240 VAC, 100 A, 10 kA Interrupt, 2 Poles, Thermal Magnetic Trip
Vendor Description
Siemens Sentron™ series circuit breakers have a long history of excellent performance in both the commercial and industrial market segments, they are tried and true in the most critical applications. Siemens Sentron™ series circuit breakers are available in nine frame sizes from 125 A to 2000 A.
Specifications
| Amperage Rating |
100
|
|---|---|
| Country of Origin |
MX
|
| Dimensions |
18 in L x 9 in W x 6 in H
|
| Enclosure |
TYPE 1F
|
| Environmental_Conditions |
Indoor
|
| Frame |
ED
|
| Frequency_Rating |
50/60
|
| Interrupt_Rating |
10
|
| Length1 |
18.0000
|
| Mounting_Type |
Flush
|
| Number_Of_Poles |
2
|
| Operating_Temperature |
(-25C -- 75C) AMBIENT TEMPERATURE
|
| Special Features |
|
| Standard |
UL
|
| Sub_Brand |
SENTRON
|
| Temperature_Rating |
-25 to 75
|
| Type |
Type ED2 Low Voltage
|
| Voltage Rating |
240
|
