Sensor Switch Sensor Switch NPODM 2P WH

Industry Description

nLight wallpod, bush-button, Two Pole, White, SKU - 204WJR

Modified Industry Description

NLIGHT WALLPOD, PUSH-BUTTON, TWO

AD Description

Sensor Switch™ NPODM 2P WH Bush-Button Network Wall Pod, <5 mA, 2 Switches, ON/OFF Operation, White

Vendor Description

The nPODM xS Series WallPods are single gang nLight-enabled devices that provide one, two, and four scene control. These units provide a convenient method of selecting a custom lighting control scene for the room in which it is installed, or requesting a global profile scene be run across several remote zones. By default, however, the buttons of an nPODM xS are configured as on/off toggle switches. Scenes are programmed to these units utilizing available SensorView software. The nPODM xS has soft-click push-buttons with a green LED indicator for each button. These button are field replaceable and can be custom engraved. Two RJ-45 connectors allow the nPODM xS to be daisy-chain wired with CAT-5e cabling to other nLight network devices. The nPODM xSB offers individual on/off buttons for each scene. Pressing the "on" button will reset the expiration time of a scene back to the original programmed time. In order to utilize a blink warning, system gateway and additional programming is required. nPODM xSB WallPods are not recommended for use with "preset" style scenes.
