Appleton Appleton LC125DCG
Appleton LC125DCG
Kirby Risk #: 3096336
UPC: 68785500062, 687855000623, 00687855000623
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Appleton
Description
Industry Description
EMT Conduit Bodies, Aluminum Threaded for Rigid Conduit and IMC, Material: Conduit body: diecast, copperfree aluminum/epoxy powder coat, Cover: stamped aluminum, natural fi nish, Gasket: neoprene, UL Standard: 514A, Trade Size: 1-1/4", L
AD Description
Appleton® NEER™ LC125DCG Type LC Conduit Outlet Body With Stamped Aluminum Cover and Neoprene Gasket, 1-1/2 in Hub, 33.4 cu-in, Die Cast Aluminum, Epoxy Powder Coated
Vendor Description
NEER™ aluminum threaded conduit bodies, covers and gaskets are used to connect and change direction of conduit runs. These conduit bodies serve as pulling fittings and permit access to conductors for splicing and maintenance.
Specifications
| Application |
Provides access to the interior of the raceway for wire pulling , splicing and maintenance, Allows connection of straight and branch conduit runs and 90 degree bends
|
|---|---|
| Country of Origin |
IN
|
| Finish |
Epoxy Powder Coated
|
| Length1 |
11.0000
|
| Material |
Die-Cast Aluminum
|
| Special Features |
|
| Standard |
UL Standard: 514A; UL Listed: E53330; CSA Standard: C22.2 No. 18.3; CSA Certified: 208044; NEMA: FB-1
|
| Sub_Brand |
NEER
|
| Type |
Conduit Body
|
