Brady Brady 3PS-500-2-WT


Description

Industry Description

BRADY IP® Series PermaSleeve® Open 3" Core Heat Shrink Polyolefin Shrink Tubing - White. Brand Name: Brady®. Sub Brand: PermaSleeve®. Type: Heat Shrink Tubing. Special Features: Heat-Shrinkable, Self-Extinguishing. Application: Cable & Wire Marking. Standard: ASTM D 2671, ASTM E 162, ASTM E 662, ASTM G 155, MIL-STD-202, SAE-AMS-DTL-23053, SAE-AS-81531, UL Recognized. Color: White. Material: Brady B-342 Heat Shrink Polyolefin. Height: 0.851 IN. Width: 2 IN. Diameter: 0.5 in Diameter as Supplied. Temperature Range: -94 to 267 DEG F. Printer Type: BRADY IP® Series Label Printer, BRADYPRINTER™ PR Plus Series Label Printer. Labels per Package: 500. Shrink Ratio: 3:1. Wire Size: 8 AWG to 1 AWG (0.187 in to 0.45 in). Number of Printable Sides: Double-Side Printable. Print Method: Thermal Transfer. Suggested Ribbon Series: R2000, R4300, R4502S, R5000, R6600, R6700. Resistance Properties: Chemical-Resistant, Corrosion-Resistant, Humidity-Resistant, Smear-Resistant, UV-Resistant, Weather-Resistant. Label/Media Format: Roll. Alternate Catalog Number: 32509.

Modified Industry Description

HEAT SHRINK TUBING

AD Description

Brady® PermaSleeve® 3PS-500-2-WT 2-Sided Wire Marker Sleeve, 8 to 1 AWG Wire, 2 in L x 2 in W, B-342 Polyolefin

Vendor Description

Brady® PermaSleeve® heat shrinkable sleeves fit snugly around wires for maximum insulation protection and permanent identification.

Specifications

Application
Cable & Wire Marking
Color
White
Conductor Size
8 AWG to 1 AWG (0.187 in to 0.45 in)
Country of Origin
US
Finish
Matte
Length1
5.3000
Material
Brady B-342 PermaSleeve® Heat-Shrink Polyolefin
Size
0.45" Diameter as Supplied
Special Features

  • 1/2 in dia as supplied
  • 2 in maximum marker width
  • 500 markers/roll
  • Brady® PermaSleeve® heat shrinkable sleeves fit snugly around wires for maximum insulation protection and permanent identification
  • Chemical, corrosion, fade, humidity, smear, smudge, UV, weather-resistant, full circle insulating sleeves
  • Heat shrinkable, with 3:1 shrink ratio, self-extinguishing, made of B-342 polyolefin material
  • LabelMark™ labeling software, CodeSoft™ 9 labeling software compatible
  • Matte finish
  • R4300, R6600, R6700 (with black sleeves) ribbon series recommended
  • Thermal transfer print technology
Standard
ASTM D 2671; ASTM E 162; ASTM E 662; ASTM G 155; MIL-STD-202; SAE-AMS-DTL-23053; SAE-AS-81531; UL Recognized
Sub_Brand
Brady®
Type
Shrink Tubing
