Ge Industrial GE Industrial TEYH3060B


Description

Industry Description

The TEY is a one-inch wide per pole, compact, "bolt-on" circuit breaker for use on grounded 480Y/277 Vac systems. The bolt-on mounting base accessory makes the TEY suitable for varied applications as a lug-lug breaker. All TEY circuit breakers feature Quick-make / Quick-break mechanisms, common trip bars, and easy to spot trip indication to ensure safety and reliability. TEYH breakers are available in 1, 2, and 3 pole versions 2&3 pole versions can be ordered with auxiliary contact, shunt trip, undervoltage release, or bell alarm accessories. TEYx Circuit Breaker 3P 60A

AD Description

GE TEYH3060B Type TEY Compact Lighting Panel Circuit Breaker With Cu/Al Load Lug, 120/240/277/480 VAC/250 VDC, 60 A, 65 kA, 35 kA, 3 Poles, LI/Non-Interchangeable/Thermal Magnetic Trip

Vendor Description

The TEY is a 1 in W per pole, compact, "bolt-on" circuit breaker for use on grounded 480Y/277 VAC systems. The bolt-on mounting base accessory makes the TEY suitable for varied applications as a lug-lug breaker. All TEY circuit breakers feature quick make/quick break mechanisms, common trip bars and easy to spot trip indication to ensure safety and reliability. TEYH breakers are available in 1, 2 and 3-pole versions, 2 and 3-pole versions can be ordered with auxiliary contact, shunt trip, under voltage release or bell alarm accessories.

Specifications

Amperage Rating
60A
Application
Electrical distribution and Control
Connection
#10-#4
Country of Origin
UKN
Frame
TEYH
Interrupt_Rating
65kA@120/240 Vac, 65kA@240 Vac,35kA@480Y/277 Vac
Length1
5.7500
Number_Of_Poles
3
Special Features

  • 65 kA at 120/240 VAC, 65 kA at 240 VAC, 35 kA at 480Y/277 VAC interrupt rating
  • Ambient compensated
  • Cost effective protection
  • Mounting base for unit mount installations
  • Multiple short circuit tiers
Standard
E11592
Sub_Brand
GE Industrial Solution
Type
Circuit Breakers
