Panduit Pan-Net Panduit Pan-Net PUP6504RD-UY
Panduit Pan-Net PUP6504RD-UY
Kirby Risk #: 2972396
UPC: 07498303096, 074983030965, 50074983030960, 00074983030965
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Panduit Pan-Net
Description
Industry Description
Copper Cable, Enhanced Category 6, 4 Pair, 23 American Wire Gauge (AWG), Unshielded Twisted Pair (UTP), CMP, Red, 1000 Feet (305 Meter). Exceeds requirements of ANSI/TIA-568-C.2 Category 6 and ISO 11801 2nd Edition Class E channel standards. Exceeds requirements of ANSI/TIA-568-C.2 and IEC 61156-5 Category 6 component standards. Meets requirements of IEEE 802.af and IEEE 802.3at for PoE applications. Reduced attenuation maximizes the amount of signal that reaches the receiver, increasing bandwidth. Third party tested to comply with ANSI/TIA/EIA-568-B.2-1. Cable diameter of 0.264 inch (6.7mm) nominal. Installation temperature range of 32 degrees F to 122 degrees F (0 degrees C to 50 degrees C). Operating temperature range of 14 degrees F to 140 degrees F (-10 degrees C to 60 degrees C). Descending length cable markings enable easy identification of remaining cable which reduces installation time and cable scrap. Cable supplied in an easy payout reel-in-a-box.
AD Description
Panduit® PUP6504RD-UY TX6500™ Premium Type CMP Cat 6 U/UTP Plenum Cable, 80 VAC, (4 Pairs) 23 AWG Bare Copper Conductor, 1000 ft L
Specifications
| Application |
Ethernet 10BASE-T, 100BASE-T (Fast Ethernet), 1000BASE-T (Gigabit Ethernet), 10GBASE-T (10 Gigabit Ethernet over limited distances as specified in the industry 10GBASE-T standards)
|
|---|---|
| Color |
Red
|
| Conductor Type |
Bare Copper
|
| Conductor Size |
23 AWG
|
| Construction |
U/UTP
|
| Country of Origin |
USA
|
| Length1 |
1000
|
| Number Of Conductors |
4 Pairs
|
| Outside_Diameter |
0.264
|
| Series |
TX6500™ Premium
|
| Special Features |
|
| Sub_Brand |
Pan-Net?®
|
| Temperature_Rating |
-4 to 140
|
| Type |
Type CMP Cat 6 U/UTP
|
| Voltage Rating |
80
|
