Panduit Panduit PCSB2/0-10-2Y


Description

Industry Description

Multi-Tap connector, double-sided, clear insulation, 10 ports, 2/0 - #14 STR.

Modified Industry Description

Multi-Tap Connector, Double-Sided,

AD Description

Panduit® Pan-Lug™ PCSB2/0-10-2Y 10-Port Double Sided Multi-Tap Connector With Clear PVC Insulation, 14 to 2/0 AWG Stranded, 14 to 10 AWG Solid Aluminum/Copper Solid/Stranded Conductor, Screw Installation, Aluminum

Specifications

Application
Aluminum or Copper Code Conductors
Brand Name
Panduit
Conductor_Range_Main_Primary
2/0 - #14 AWG STR #10 - #14 AWG SOL
Conductor Type
Solid/Stranded
Conductor Size
14 to 2/0 AWG Stranded/14 to 10 AWG Solid Al/Cu
Country of Origin
USA
Insulation
Clear PVC
Material
Aluminum
Number_Of_Holes
10
Number_Of_Mounting_Holes
NA
Number_Of_Ports
10
Package_Quantity
1
Special Features

  • Body made from high strength, extruded aluminum alloy to provide premium electrical and mechanical performance
  • Dual sided entry allows offset and opposite entry for primary and secondary conductors
  • Each port pre-filled with oxide inhibiting joint compound seals out air and moisture to deter surface oxidation
  • Flexible design can be used as a tap, splice or dead end connector
  • Insulated with clear PVC to eliminate the need for taping and allow for visual inspection of the complete conductor insertion
  • Plated steel or aluminum set screw provides high strength, durable electrical contact between conductor and connector
  • Wide wire range taking capability minimizes inventory requirements
Standard
486A-486B File #E52164
Sub_Brand
Panduit
Temperature_Rating
90
Type
10-Port Double Sided
Voltage Rating
600
