Panduit Panduit LCMB240-20-6
Panduit LCMB240-20-6
Kirby Risk #: 2966591
UPC: 07498362278, 074983622788, 30074983622789, 00074983622788
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Panduit
Description
Industry Description
One-hole, metric conductor, long barrel, 240mm² 2r, 185mm² class 5f/6f, M20 stud hole.
Modified Industry Description
Copper Compression Metric Lug, 1
AD Description
Panduit® Pan-Lug™ LCMB240-20-6 1-Hole Metric Lug Compression Connector With Window Lug, 185 sq-mm/240 sq-mm, Die Code: P87, M20 Stud, Tin Plated Copper
Specifications
| Amperage Rating |
NA
|
|---|---|
| Country of Origin |
IND
|
| Material |
High conductivity seamless copper tube
|
| Special Features |
|
| Standard |
Meets EN 61238-1:2003/IEC 61238-1:2003 Class B
|
| Sub_Brand |
Panduit
|
| Type |
Tin-Plated CopperCompression Connectors - Metric Lugs
|
| Voltage Rating |
35k
|
