Panduit Panduit LCD1-38D-E
Panduit LCD1-38D-E
Kirby Risk #: 2966087
UPC: 07498338295, 074983382958, 00074983382958
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Panduit
Description
Industry Description
Two-hole, standard barrel lug with window, #1 AWG wire, 3/8 stud hole, 1 hole spacing.
Modified Industry Description
COPPER COMPRESSION LUG, 2 HOLE, #1
AD Description
Panduit® Pan-Lug™ LCD1-38D-E 2-Hole Compression Lug, 1 AWG Copper Conductor, Die Code: P37, 3/8 in Stud, Tin Plated Copper
Specifications
| Color |
Green
|
|---|---|
| Conductor Type |
Copper
|
| Conductor Size |
1
|
| Country of Origin |
MEX
|
| Length1 |
4.7500
|
| Material |
Tin Plated Copper
|
| Mounting |
15/16
|
| Series |
LCD
|
| Size |
#1 Code
|
| Special Features |
|
| Standard |
CSA certified C22.2 No. 65-13, UL Listed to 486A-486B File #E52164, NEBS Level 3
|
| Sub_Brand |
Panduit
|
| Temperature_Rating |
90
|
| Type |
2-Hole
|
| Voltage Rating |
35
|
