Panduit Panduit LCCX250-14B-X


Description

Industry Description

Two-hole, flex lug, long barrel, 250 kcmil cable, 1/4 stud hole, .75 hole spacing.

Modified Industry Description

Copper Compression Lug, 2 Hole, 250

AD Description

Panduit® Pan-Lug™ LCCX250-14B-X 2-Hole Lug Compression Connector With Window Lug, 250 kcmil/262.6 kcmil Flexible Conductor, Die Code: P62, 1/4 in Stud, Tin Plated Copper

Specifications

Color
Yellow
Country of Origin
MEX
Material
Tin-Plated Copper
Mounting
2 5/16
Size
250 kcmil Class G, H, I, K, M and 262.6 kcmil DLO
Special Features

  • Color coded barrels marked with Panduit® and specified competitor die index numbers for proper crimp die selection
  • Generously beveled wire entry prevents bent back strands when inserting conductor into barrel
  • Inspection window to visually assure full conductor insertion
  • Long barrel maximizes number of crimps and provides premium wire pull out strength and electrical performance
  • Tin plated to inhibit corrosion
Sub_Brand
Panduit
Type
Type LCCX
Voltage Rating
35k
