Panduit Panduit LCD300-38D-X

Name: Panduit LCD300-38D-X
Brand: Panduit
SKU: 2809572
Price: 2845.07 USD
Availability: InStock

Panduit LCD300-38D-X

Kirby Risk #: 2809572

UPC: 07498371959, 074983719594, 00074983719594

Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)

Brand: Panduit

Description

Industry Description

Two-hole, standard barrel lug with window, 300 kcmil cable, 3/8 stud hole, 1 hole spacing.

Modified Industry Description

Copper Compression Lug, 2 Hole, 300

AD Description

Panduit® Pan-Lug™ LCD300-38D-X 2-Hole Lug Compression Connector With Window Lug, 300 kcmil, Die Code: P66, 3/8 in Stud, Tin Plated Copper

Color	White
Country of Origin	MEX
Length1	7.9000
Material	Tin-Plated Copper
Mounting	1 1/2
Size	300 kcmil Code
Special Features	Color coded barrel Color coded barrels marked with Panduit® and specified competitor die index numbers for proper crimp die selection Inspection window to visually assure full conductor insertion Tin plated to inhibit corrosion
Standard	CSA certified C22.2 No. 65-13, UL Listed to 486A-486B File #E52164, NEBS Level 3
Sub_Brand	Panduit
Type	Tin-Plated Copper Compression Connectors - Lugs
Voltage Rating	35k
