Bussmann Bussmann GMD-1.25-R

Name: Bussmann GMD-1.25-R
Brand: Bussmann
SKU: 2591042
Price: 7.31 USD
Availability: InStock

Bussmann GMD-1.25-R

Kirby Risk #: 2591042

UPC: 05171265780, 051712657808, 00051712657808

Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)

Brand: Bussmann

Description

Industry Description

1.25A 250V 5mm x 20mm RoHS Compliant Glass, Time Delay Fuse

Modified Industry Description

1.25A 250V GLASS TIME DELAY FUSE 5 X 20 MM

AD Description

Bussmann GMD-1.25-R Low Breaking Small Dimension Time Delay Fuse With Nickel Plated Brass End Caps, 1.25 A, 250 VAC, 100 A, 10 kA, Cylindrical Body

Amperage Rating	1.25
Application	Electronic Circuits
Class	I4
Connection	Ferrule End X Ferrule End
Country of Origin	CN
Length1	1.6250
Size	5.20 mm Diameter X 20.00 mm Height
Special Features	100 A at 250 VAC, 10 kA at 125 VAC interrupt rating 60 min maximum at 135%, 2 min minimum at 200%, 5 sec maximum at 200% response time Time delay compatibility for inductive circuits
Standard	UL 248-14, CSA, CE, PSE/JET
Sub_Brand	Cooper Bussmann
Type	Electronic, Time Delay
Voltage Rating	250
