3M 3M MNU14-250DMIK
3M MNU14-250DMIK
Kirby Risk #: 2579107
UPC: 05400702300, 054007023005, 00054007023005
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: 3M
Description
Industry Description
3M™ Scotchlok™ Color-Coded Male Disconnect Terminal offers superior holding force while allowing for quick and easy disconnect. The terminal has a fully insulated, nylon, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Its electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.
Modified Industry Description
FULLY NYLON INSULATED BUTTED SEAM
AD Description
Scotchlok™ MNU14-250DMIK Disconnect Tab, 16 to 14 AWG Conductor, 1/4 in Tab, 0.085 in ID x 0.25 in L Butted Barrel, ETP Copper, Blue
Vendor Description
Helps eliminate mistakes during crimping with our 3M™ Scotchlok™ Color-Coded Male Disconnect Terminal. The nylon sleeve is fully insulated, providing a layer of protection, and it’s resistant to abrasions to make it durable. A tongue on this blue terminal makes it compatible with its female counterpart, and the butted-seam barrel ensures that crimping doesn’t halt electrical contact. This disconnect terminal is RoHS 2011/65/EU Compliant, CSA Certified and UL Listed.
Specifications
| Color |
Blue
|
|---|---|
| Conductor Type |
Fully Insulated
|
| Conductor Size |
16 to 14 AWG
|
| Country of Origin |
US
|
| Dimensions |
0.032 in THK x 1/4 in W Pad
|
| Length1 |
5.3000
|
| Material |
ETP Copper
|
| Special Features |
|
| Standard |
UL and CSA
|
| Sub_Brand |
3M
|
| Temperature_Rating |
-40 to 221 deg F
|
| Type |
Disconnect
|
| Voltage Rating |
600 VAC
|
