3M 3M BSV10Q


Description

Industry Description

3M™ Highland™ Color-Coded Butt Splice Connector ensures an ideal fit while offering reliable and safe performance. The connector has a vinyl-insulated, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). The electrolytic copper terminal offers good conductivity and a tin-plated finish resists corrosion.

Modified Industry Description

VINYL BUTT CONNECTOR 25/BAG

AD Description

Highland™ 051128-59996 Insulated Butt Splice Connector, 12 to 10 AWG Conductor, 1.02 in L, Butted Barrel, Yellow

Specifications

Color
Yellow
Conductor Type
Copper
Connection
Butt
Conductor Size
12 to 10 AWG
Country of Origin
US
Length1
1.02 in
Material
PVC
Special Features

  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Accommodates wire sizes 12 to 10 AWG
  • Built-in wire stop for correct positioning
  • Funnel-designed, polyvinyl chloride sleeve offers easy insertion of wires
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
  • Withstands a temperature range of -40 to 221 degrees F
  • Yellow vinyl-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
Standard
UL and CSA
Sub_Brand
3M
Temperature_Rating
-40 to 221 deg F
Type
Insulated
Voltage Rating
600 VAC
