Panduit Panduit LCCF8-14A-L

Name: Panduit LCCF8-14A-L
Brand: Panduit
SKU: 2547241
Price: 342.93 USD
Availability: InStock

Panduit LCCF8-14A-L

Kirby Risk #: 2547241

UPC: 07498375287, 074983752874, 00074983752874

Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)

Brand: Panduit

Description

Industry Description

Two-hole, long flared barrel, #8 AWG wire, 1/4 stud hole, 5/8 hole spacing, NEMA hole sizes and spacing.

Modified Industry Description

Copper Compression Lug, 2 Hole, #8

AD Description

Panduit® Pan-Lug™ LCCF8-14A-L 2-Hole Compression Lug, 8 AWG DLO Copper Conductor, Die Code P21, 1/4 in Stud, Tin Plated Copper

Color	Red
Conductor Type	Copper
Conductor Size	8 AWG DLO
Country of Origin	MEX
Material	Tin Plated Copper
Mounting	13/16
Series	LCCF
Size	#8 DLO
Special Features	Can be used with flex conductor class K, M and diesel locomotive Color-coded barrels marked with Panduit die index numbers for proper crimp die selection Enclosed barrel prevents corrosive material from entering barrel when used in harsh environments Flared entry prevents bent back strands when inserting fine strand conductor into barrel For Use with flexible and extra-flexible copper conductors Long barrel maximizes the number of crimps and provides premium wire pull-out strength and electrical performance Tin-plated to inhibit corrosion
Sub_Brand	Panduit
Temperature_Rating	90
Type	2-Hole
Voltage Rating	35
