Siemens Siemens B380HH00S01


Description

Industry Description

Siemens Low Voltage Molded Case Circuit Breakers Panelboard Mounting 240V Circuit Breakers - Type BL, 3-Pole, 240VAC are Circuit Protection Molded Case CircuitBreakers. Type HBL Special Features Shunt Trip 120V Application Electrical Distribution Standard UL 489 Voltage Rating 120/240V Amperage Rating 80A Trip Range Thermal Magnetic Interrupt Rating 65 AIC Number Of Poles 3P

Modified Industry Description

BREAKER 80A 3P 240V 65K HBL 120V

AD Description

Siemens B380HH00S01 Type HBL Low Voltage Molded Case Circuit Breaker, 120/240 VAC, 80 A, 65 kA Interrupt, 3 Poles, Shunt/Thermal Magnetic Trip

Vendor Description

Circuit breakers provide a manual means of energizing and de-energizing a circuit. In addition, circuit breakers provide automatic over current protection of a circuit. A circuit breaker allows a circuit to be reactivated quickly after a short circuit or overload is cleared. Unlike fuses, which must be replaced when they open, a simple flip of the breakers operating handle restores the circuit.

Specifications

Actuator
N/A
Amperage Rating
80
Application
Electrical Distribution
Connection
BOLT-ON
Country of Origin
MX
Dimensions
6 in L x 4 in W x 4 in H
Enclosure
N/A
Environmental_Conditions
N/A
Frame
HBL
Frequency_Rating
60
Interrupt_Rating
65
Length1
6.0000
Material
N/A
Mounting_Type
Panel
Number_Of_Poles
3
Operating_Temperature
N/A
Phase
3
Special Features

  • 120 VAC shunt trip
  • 4 to 1/0 AWG copper, 2 to 2/0 AWG aluminum wire
  • Act by tripping quickly enough to prevent damage to itself and associated conductors
  • Measure the amount of over current
  • Mounting with insta-wire
  • Sense when an over current occurs
Standard
ULLISTED/CSA/NOMCERTIFIED
Sub_Brand
N/A
Temperature_Rating
40
Type
Low Voltage
Voltage Rating
120/240
