Burndy Burndy TP1012


Description

Industry Description

Ring Tongue Terminal, Polyvinylchloride, 600 VOLTS MAX. 105 Deg C MAX.

Modified Industry Description

RING TERMINAL 12 - 10 AWG VINYL

AD Description

BURNDY® HYDENT TP1012 Type TP Insulated Ring Terminal, 12 to 10 AWG Conductor, 1.51 in L, Deep V-Groove Serrated Barrel, Pure Electrolytic Copper, Blue

Specifications

Application
For Commercial And Light Duty Industrial Control And Power Circuit Applications
Color
Blue
Conductor Type
Solid/Stranded Copper
Conductor Size
12 to 10
Country of Origin
US
Finish
Electro-Plated Tin
Insulation
PVC
Length1
1.51
Material
Pure Electrolytic Copper
Special Features

  • Deep V groove serrations in the inner barrel: provides added holding strength and better conductivity
  • Electro-tin plated: provides durable long-lasting corrosion resistance
  • Funnel entry: easy wire insertion
  • Low resistance and ductility for excellent crimp forming properties
  • Manufactured of pure electrolytic copper: provides maximum conductivity
  • Many tongue variations and rated 600 v makes TP terminals versatile and economical expanded insulation support accepts standard and large wire diameters: lowers inventory requirements
  • Permits greater flexibility and provides insulation support
  • Supplied with an expanded polyvinyl chloride (pvc) insulation shroud
Standard
UL Listed, CSA Certified
Sub_Brand
Burndy
Temperature_Rating
105
Type
Type TP Insulated
Voltage Rating
600
