Siemens Siemens WP6511RJ
Siemens WP6511RJ
Kirby Risk #: 2509009
UPC: 04089287569, 040892875690, 00040892875690
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Siemens
Description
Industry Description
Siemens Low Voltage s Multi-Family Metering Line of PAK Metering Standard 125A as part of the PAK Metering Standard 125A Group. Type UNI-PAK Features NO BYPASSAppn GARDEN - STYLE Std UL-50,67,414 V. Rating 120/240V A. Rating 600A Phase 1PH Size 9.000x45.07 x 39.690 No. Of Cutouts 17 Cutout Size 1 x (1/2,3/4,1,1-1/4 ), 12 x (2-1/2,2 ,1-1/2,1-1/4,1 ), 2 x (4,3-1/2,3,2-1/2,2 ), 2X4 Cable Entry TOP OR BOTTOM FEED Terminal 3X2 STUDS. Insulated.Appn . Wall Mounted. Enclosure RINGLESS
Modified Industry Description
600A 5J 125A/5POS RGLS PAK NO BPS
AD Description
Siemens UNI-PAK WP6511RJ 17-Cutout 3-Wire Insulated Low Voltage Meter Pack, 125 A, Overhead/Underground Feed, 120/240 VAC, 600 A Bus
Vendor Description
Siemens Uni-PAK metering offers maximum flexibility and ease of installation to meet the service requirements of multiple position metering projects. The outdoor/indoor devices are available in two through six gang set-ups which consist of a pull section with main lugs or stud terminations and 4/5 jaw meter sockets with tenant circuit breaker provisions.
Specifications
| Amperage Rating |
600
|
|---|---|
| Application |
SERVICEENTRANCEEQUIPMENT
|
| Country of Origin |
US
|
| Enclosure |
Ringless
|
| Frequency_Rating |
TRUE
|
| Length1 |
39.6900
|
| Mounting |
SURFACEMOUNTING
|
| Phase |
1
|
| Size |
5
|
| Special Features |
|
| Standard |
UL50/UL67/UL414
|
| Sub_Brand |
Uni-PAK
|
| Type |
METERSTACK
|
| Voltage Rating |
120
|
