Siemens Siemens 3NA3812
Siemens 3NA3812
Kirby Risk #: 2435335
UPC: 01869057002, 75455415247, 754554152479, 00754554152479
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Siemens
Description
Industry Description
FUSE LINK,LV HRC,32A,500VAC,250VDC W. NON-INSULATED GRIP LUGS LV HRC FUSE LINK GL/GG 00,32A
Modified Industry Description
FUSE LINK,LV HRC,32A,500VAC,250VDC
AD Description
Sentron™ 3NA3812 HRC Design Low Voltage Fuse Link, 500 VAC, 32 A, Ceramic
Vendor Description
LV HRC fuse systems (NH type) are used for installation systems in non-residential, commercial and industrial buildings as well as in switchboard assemblies of power utilities. They therefore protect essential building parts and systems. LV HRC fuse systems (NH type) are fuse systems designed for operation by experts. There are no constructional requirements for non-interchangeability of rated current and touch protection. The components and auxiliary equipment are designed in such a way as to ensure the safe replacement of LV HRC fuse systems or isolation of systems.
Specifications
| Amperage Rating |
32
|
|---|---|
| Application |
SUPPLEMENTARY PROTECTION
|
| Class |
gG
|
| Connection |
LV HRC FUSE BASE
|
| Country of Origin |
DE
|
| Dimensions |
77.8 mm L x 52.5 mm W x 21 mm D
|
| Frequency_Rating |
N/A
|
| Interrupt_Rating |
120kA
|
| Length1 |
2.6000
|
| Material |
Ceramic
|
| Mounting |
ANY
|
| Size |
NH000
|
| Special Features |
|
| Standard |
VDE, GL, KEMA, GOST, CCC
|
| Sub_Brand |
SENTRON
|
| Temperature_Rating |
-20 to 50
|
| Type |
HRC Design
|
| Voltage Rating |
500
|
