Siemens Siemens HNF463
Siemens HNF463
Kirby Risk #: 2425861
UPC: 78364348842, 783643488427, 00783643488427
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Siemens
Description
Industry Description
Siemens Low Voltage Circuit Protection Heavy Duty Safety Switch. 4-Pole Non-Fused in a type 1 enclosure (indoor). Rated 600VAC (100A).
Modified Industry Description
HDSS NF 4P4W 600V 100A N1
AD Description
Siemens HNF463 Enclosed Heavy Duty Non-Fusible Safety Switch, 600 VAC, 100 A, 100 hp, ST Contact Form, 4 Poles
Vendor Description
4 & 6-pole switches are available in 30 to 200 A ratings and in both fusible and non-fusible versions. 4-pole switches are supplied with either Type 1 or Type12/3R enclosures. 6-pole switches are available with either Type 12/3R or Type 4X stainless steel enclosures.
Specifications
| Action |
SINGLE THROW
|
|---|---|
| Actuator |
SINGLETHROW
|
| Amperage Rating |
100
|
| Application |
DISCONNECTINGMEANFORTWO-SPEED/TWO-WINDINGMOTORS
|
| Connection |
MECHANICALLUGS
|
| Country of Origin |
MX
|
| Enclosure |
NEMA1
|
| Environmental_Conditions |
Indoor
|
| Frequency_Rating |
TRUE
|
| Insulation |
None
|
| Length1 |
7.5600
|
| Material |
Steel
|
| Mounting |
Surface
|
| Number_Of_Poles |
4
|
| Operating_Temperature |
-29
|
| Special Features |
|
| Standard |
UL98
|
| Sub_Brand |
VBII
|
| Type |
HEAVYDUTYSWITCH
|
| Voltage Rating |
600
|
| Wattage |
4
|
