Thomas & Betts Thomas & Betts RH717
Thomas & Betts RH717
Kirby Risk #: 2353859
UPC: 78621082117, 786210821177, 30786210821178
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Thomas & Betts
Description
Industry Description
Nylon Insulated Large Ring Terminal, Length 2.14 Inches, Width .77 Inches, Maximum Insulation .629, Bolt Hole 1/4 Inch, Wire Range 1/0, Color White, Copper, Tin Plated, 50 Pack
Modified Industry Description
INS NYL RING TERM, 1/0, 1/4, CLEAR
AD Description
Sta-Kon® RH717 RH Series Insulated Ring Terminal, 1/0 AWG Conductor, 2.14 in L, Brazed/Overlapped Seam Barrel, Copper, White
Vendor Description
Sta-Kon® wire terminals offer more copper and a wider funnel to assure premium connection with less work in a line that includes insulated and non-insulated terminals, splices, wire joints, disconnects, ferrules, heat shrinkable terminals, splices and disconnects.
Specifications
| Color |
White
|
|---|---|
| Conductor Size |
1/0
|
| Country of Origin |
MX
|
| Finish |
Tin Plated
|
| Length1 |
2.14
|
| Material |
Copper
|
| Series |
RH Series
|
| Special Features |
|
| Standard |
UL E9809
|
| Sub_Brand |
Sta-Kon
|
| Temperature_Rating |
105
|
| Type |
Insulated
|
| Voltage Rating |
600
|
