3M 3M MNG18-6FX


Description

Industry Description

3M™ Scotchlok™ Color-Coded Standard Fork is a lug connection terminal that has a wider tongue for use on free-standing studs. The terminal has a nylon-insulated, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.

Modified Industry Description

NYLON INSULATED W/INSULATION GRIP

AD Description

Scotchlok™ 051128-58650 Insulated Standard Fork Terminal, 22 to 18 AWG Conductor, 0.89 in L, Butted Seam Barrel, Copper, Red

Vendor Description

3M™ Scotchlok™ Color-Coded Standard Fork is a lug connection terminal that has a wider tongue for use on free-standing studs.

Specifications

Color
Red
Conductor Type
Stranded Copper
Conductor Size
22 to 18 AWG
Country of Origin
US
Finish
Electro-Tin Plated
Length1
0.89 in
Material
Copper
Special Features

  • Abrasion and corrosion resistant, flared, nylon-sleeve insulation ensures a positive grip and has a stepped design for mistake-proof crimping
  • Crimp termination
  • Electrolytic copper construction offers good conductivity
  • Free hanging (in-line) mounting
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires
  • Red nylon-insulated grip, butted seam barrel ensures a secure fit and offers reliable performance
  • Wider-tongue design for use on free-standing studs
Standard
UL and CSA
Sub_Brand
3M
Temperature_Rating
-40 to 221 deg F
Type
Insulated Standard
Voltage Rating
600/1000 VAC
