Panduit Panduit LCC4-14DW-L


Description

Industry Description

Two-hole, long barrel lug with window, #4 — #3 AWG STR, #2 AWG SOL wire, 1/4 stud hole, 1 hole spacing.

Modified Industry Description

3 AWG 1/4 IN 2 HOLE LONG CU COMP LUG

AD Description

Panduit® Pan-Lug™ LCC4-14DW-L 2-Hole Lug Compression Connector, 4 to 3 AWG/2 AWG Stranded/Solid Conductor, Die Code: P29, 1/4 in Stud, Tin Plated Copper

Specifications

Color
Gray
Country of Origin
MEX
Length1
5.8000
Material
Tin-Plated Copper
Mounting
1 1/8
Size
#4 – #3 Code STR, #2 Code SOL
Special Features

  • Color coded barrels marked with Panduit® and specified competitor die index numbers for proper crimp die selection
  • Enclosed barrel prevents corrosive material from entering barrel when used in harsh environments
  • Long barrel maximizes number of crimps and provides premium wire pull out strength and electrical performance
  • Tin plated to inhibit corrosion
  • Without inspection window lug
Standard
CSA certified C22.2 No. 65-13, UL Listed to 486A-486B File #E52164, ABS approved, NEBS Level 3
Sub_Brand
Panduit
Type
Tin-Plated Copper Compression Connectors - Lugs
Voltage Rating
35k
