Description

Industry Description

PVC Coated Conduit Body, LL Shape, Form 8 UL-4X, Size 3/4 Inch/21 Metric, Iron, Dark Gray

Modified Industry Description

3/4 IN FORM 8 PVC COATED LL CONDUIT BODY, DARK GRAY

AD Description

Ocal® OCAL-BLUE® LL28-4X-G Type LL Conduit Body, 3/4 in Hub, Form 8 Form, 8 cu-in Capacity, Iron, PVC Coated

Vendor Description

With outstanding performance in corrosive environments, Ocal® PVC coated conduit and fittings extend the life of your electrical system for many years beyond the lifespan of standard rigid conduit systems. T&B® has removed certain "Only Ocal®" statements from its literature and advertising as part of the settlement of a lawsuit.

Specifications

Application
Act as pull outlets for conductors being installed
Brand Name
Ocal
Color
Dark Gray
Configuration
LL
Country of Origin
US
Finish
PVC Coated
Form
8
Hub_Size
3/4
Material
Iron
Special Features

  • Connect conduit sections, make 90 deg bends in conduit runs
  • Double coated superior corrosion protection, bodies and covers coated inside and out with 0.002 in blue urethane, then exterior coated with a minimum of 0.04 in PVC
  • Provide for access to conductors for maintenance and future system changes
  • Provide openings for making splices and taps in conductors
  • Provide taps for branch conduit runs
  • PVC coated cast iron conduit body comes with mated cast iron cover, injection molded with an integral O-ring seal and stainless steel encapsulated screws
  • UL listed type 4X and NEMA 4X rating for excellent protection in wash down areas, as well as harsh outdoor environments exposed to moisture, rain, ice or snow
Standard
E 2969
Sub_Brand
Ocal
Trade_Size
3/4
Type
Type LL
Width_2
7.5000
