Siemens Siemens ED41B035
Siemens ED41B035
Kirby Risk #: 2317447
UPC: 78364320912, 783643209121, 00783643209121
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Siemens
Description
Industry Description
SIEMENS LOW VOLTAGE SENTRON MOLDED CASE CIRCUIT BREAKER WITH THERMAL - MAGNETICTRIP UNIT. STANDARD 40 DEG C BREAKER ED FRAME WITH STANDARD BREAKING CAPACITY. 35A 1-POLE (22KAIC AT 277V). NON-INTERCHANGEABLE TRIP UNIT. SPECIAL FEATURES LOAD LUGS ONLY (LD1E060) WIRE RANGE 10 - 4AWG (CU/AL). DIMENSIONS (W x H x D) IN 1.00 x 6.4 x 3.92.
AD Description
Sentron™ ED41B035 Low Voltage Molded Case Circuit Breaker With Load Lugs, 277/120 VAC/125 VDC, 35 A, 22 kA Interrupt, 1 Poles, Thermal Magnetic Trip
Specifications
| Actuator |
Varying
|
|---|---|
| Amperage Rating |
35
|
| Application |
Standard 40C Breaker
|
| Connection |
N/A
|
| Country of Origin |
MX
|
| Dimensions |
6 in L x 1 in W x 5 in H
|
| Enclosure |
Varying
|
| Environmental_Conditions |
N/A
|
| Frame |
ED4
|
| Frequency_Rating |
50/60
|
| Interrupt_Rating |
22
|
| Length1 |
5.0000
|
| Material |
N/A
|
| Number_Of_Poles |
1
|
| Operating_Temperature |
40C
|
| Phase |
1
|
| Special Features |
|
| Standard |
HACR
|
| Sub_Brand |
SENTRON
|
| Temperature_Rating |
40
|
| Type |
Low Voltage
|
| Voltage Rating |
277/120 VAC/125 VDC
|
