Panduit Panduit PISR250-1


Description

Industry Description

Splicer/Reducer, dual rated for use with copper or aluminum conductors, clear insulation, 250 kcmil - #10 SOL.

Modified Industry Description

250 TO 10 AWG SPLICER / REDUCER

AD Description

Panduit® Pan-Term® PISR250-1 Dual Rated Inline Multi-Tap Splicer/Reducer, 10 AWG to 250 kcmil Stranded, 10 to 8 AWG Solid Solid/Stranded Copper/Aluminum Conductor, Screw Installation, Aluminum Alloy

Vendor Description

Panduit® Pan-Term® splices are designed and manufactured for fast assembly, and long reliable performance. As the demand for splices increases, it becomes essential to provide a complete system for termination products. We provide an extensive line of tooling designed specifically to provide optimum performance when used as a system for terminating.

Specifications

Brand Name
Panduit
Cable_Size
250 - 10
Color
No Color Code
Conductor Type
Solid/Stranded Copper/Aluminum
Connection
Mechanical
Conductor Size
250 kcmil to 10 AWG Stranded/8 to 10 AWG Solid
Country of Origin
MEX
Finish
Tin Plated
Insulation
Vinyl
Material
Aluminum Alloy
Number_Of_Holes
2
Package_Quantity
1
Special Features

  • Dual rated for use with copper or aluminum conductors
  • Each port pre-filled with oxide inhibiting joint compound seals out air and moisture to deter surface oxidation
  • Flexible design can be used as a splice or reducer
  • Insulated with clear PVC to eliminate the need for taping and allow for visual inspection of the complete conductor insertion
  • Made from high strength, extruded aluminum alloy to provide premium electrical and mechanical performance
  • Plated steel or aluminum set screw provides high strength, durable electrical contact between conductor and connector
  • Wide wire range taking capability minimizes inventory requirements
Standard
CSA Certified/UL Listed
Sub_Brand
Panduit
Temperature_Rating
90
Type
Dual Rated In-Line Multi-Tap
Voltage Rating
600
