Bussmann Bussmann CCP-2-60CF
Bussmann CCP-2-60CF
Kirby Risk #: 2299494
UPC: 05171220150, 051712201506, 00051712201506
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Bussmann
Description
Industry Description
COMPACT CIRCUIT PROTECTOR, 2 POLE,60A CF
Modified Industry Description
Compact Circuit Protector 2P 60A
AD Description
Bussmann CCP-2-60CF Compact Circuit Protector, 600 VAC/125 VDC, 60 A, 2 Poles, CUBEFuse™ Class J Fuse, 4 AWG Wire
Vendor Description
The revolutionary Bussmann series compact circuit protector (CCP) fused disconnect switch with CUBEFuse™ is 2/3 the footprint of a traditional fusible switch and provides a high 200 kA SCCR that can help increase assembly SCCR.
Specifications
| Actuator |
Padlockable Handle
|
|---|---|
| Amperage Rating |
60
|
| Brand Name |
Bussmann
|
| Connection |
Box Lug
|
| Country of Origin |
MUL
|
| DimensionsInches |
3.6500 IN X 2.0700 IN X 3.1400 IN
|
| Fuse_Type |
Class CF
|
| Mounting |
35 mm DIN Rail
|
| Number_Of_Poles |
2
|
| Operating_Temperature |
-20 to 75
|
| Size |
3.00 In Width X 3.00 In Depth X 4.50 In Height
|
| Special Features |
|
| Standard |
UL 98, C 22.2, CE
|
| Sub_Brand |
Cooper Bussmann
|
| Type |
Compact
|
| Voltage Rating |
600
|
