Panduit Panduit GCE250-250

Name: Panduit GCE250-250
Brand: Panduit
SKU: 2253751
Price: 43.94 USD
Availability: InStock

Panduit GCE250-250

Kirby Risk #: 2253751

UPC: 07498300956, 074983009565, 00074983009565

Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)

Brand: Panduit

Description

Industry Description

"E" style grounding connector for 1/0 STR Â– 250 kcmil (70 Â– 120mmÂ²) main and tap.

Modified Industry Description

1/0 TO 250 MAIN 1/0 TO 250 TAP E STYLE GROUNDING CONNECTOR

AD Description

Panduit® StructuredGround™ GCE250-250 Type GCE Grounding Connector, 1/0 AWG Stranded to 250 kcmil Max Run/Tap, 1/2 to 5/8 in Rod, Copper

Application	Utility/Ground Grid
Brand Name	Panduit
Clamp_Material	High Conductivity Copper
Color	Black
Conductor Range	1/0-250
Country of Origin	MEX
Material	Copper
Number_Of_Holes	0
Package_Quantity	1
Special Features	Color coded and marked with Panduit® die index numbers for proper crimp die selection Pre-applied conductive antioxidant compound ensures a high quality mechanical and electrical bond, speeding installation Slotted design allows quick and easy assembly of conductor to connector using Panduit® cable ties included Wide range taking ability and multi-conductor design provide flexibility with a minimum number of parts, allowing for conductor to conductor, conductor to rebar and conductor to ground rod applications
Standard	IEEE Std 837-2002, cULus listed, UL467, CSA 22.2
Sub_Brand	Panduit
Type	Type GCE
