Hubbell Hubbell HBL7853D
Hubbell HBL7853D
Kirby Risk #: 2248058
UPC: 78358520287, 783585202877, 00783585202877
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Hubbell
Description
Industry Description
Hubbell Wiring Device Kellems, Switches and Lighting Controls,Industrial Grade, Manual Motor Controllers, Motor Disconnects, ThreePole, 50A 600V AC, Side Wired Only
Modified Industry Description
50A 600V 3P DISC SW
AD Description
Wiring Device-Kellems Circuit-Lock® HBL7853D Standard AC Motor Disconnect Switch, 600 VAC, 50 A, 25 hp, 3 Poles
Specifications
| Amperage Rating |
50
|
|---|---|
| Application |
Motor Starting w/o Overload Protection
|
| Brand Name |
Hubbell
|
| Connection |
Pressure Screw Terminals
|
| Country of Origin |
PR
|
| Enclosure |
None
|
| Environmental_Conditions |
Indoor Dry unless Protected by Additional Means
|
| Material |
Stainless Steel
|
| Mounting |
Screw Mount
|
| Number_Of_Poles |
3
|
| Operating_Cycles |
10k
|
| Operating_Temperature |
Minimum Continuous -40 Deg C without Impact
|
| Phase |
3
|
| Size |
Standard Sized Product
|
| Special Features |
|
| Standard |
UL508
|
| Sub_Brand |
Hubbell Wiring Device-Kellems
|
| Type |
Open Switch
|
| Voltage Rating |
600
|
| Width_2 |
4.0480
|
| Width_3 |
13.1250
|
| Width_4 |
13.1250
|
