Thomas & Betts Thomas & Betts 54145UB
Thomas & Betts 54145UB
Kirby Risk #: 2203929
UPC: 78621071479, 786210714790, 00786210714790
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Thomas & Betts
Description
Industry Description
Copper One-Hole Lug, 90 Degree Bend Standard Barrel, Peep Hole, Max 35kV, Wire Size #2 AWG, 1/2 Inch Bolt Size, Tin Plated, Die Code 33, Die Color Code Brown
Modified Industry Description
SHORT BARREL, 1 HOLE, 90 BEND
AD Description
Color-Keyed® 54145UB 54100 1-Hole Compression Connector Lug With Peep Hole and Inspection Hole, 2 AWG Copper Conductor, Die Code: 33, 1/2 in Stud, Copper
Vendor Description
The Color-Keyed® compression system ensures a proper crimp onto the conductor by matching the right connector to the right tool and die, using a color coding system that was developed and introduced to the industry by T&B®. When using the Color-Keyed® compression system with our Blackburn® line of compression connectors, the installer can count on a reliable, high quality connection.
Specifications
| Color |
Brown
|
|---|---|
| Conductor Type |
Copper
|
| Conductor Size |
2
|
| Country of Origin |
MX
|
| Insulation |
None
|
| Length1 |
2.7500
|
| Material |
Copper
|
| Series |
54100
|
| Special Features |
|
| Standard |
UL E9809
|
| Sub_Brand |
Color-Keyed
|
| Type |
1-Hole
|
| Voltage Rating |
600 VAC to 35 kV
|
