SolaHD SolaHD IE210
SolaHD IE210
Kirby Risk #: 2201169
UPC: 63391407433, 633914074333, 00633914074333
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: SolaHD
Description
Industry Description
Islatrol IE Series Active Tracking Filter, 240 V/Continuous Current 10 Amps
Modified Industry Description
ISLATRL E 1PH 10A 240V DIN
Specifications
| Amperage Rating |
5
|
|---|---|
| Application |
Critical industrial loads drawing up to 20 Amps of continuous current, microprocessor-based products, including industrial PLCs, OEM applications, and motion control systems.
|
| Class |
Category A Ringwave (6kv, 200 A, 100 kHz)
|
| Connection |
IEC 998 approved terminals
|
| Country of Origin |
MX
|
| Environmental_Conditions |
Humidity: 0 to 95%
|
| Frequency_Rating |
47-63
|
| Length1 |
7.2000
|
| Mounting |
DIN/Flange
|
| Operating_Temperature |
-40°C to +45°C at Full Load; Derate Linearly to 60% at +70ºC
|
| Phase |
1
|
| Size |
4.06 Length X 3.06 Width X 3.83 High
|
| Special Features |
Surge current capacity — 45,000 Amps; Transient protection in all modes: line to neutral, line to ground, and neutral to ground; LED status indication and form C contact for remote indication; DIN mountable enclosure
|
| Standard |
ANSI/UL 1449 Third Edition Type 4,1283, CUL recognized, CE, ROHS
|
| Sub_Brand |
SolaHD
|
| Type |
Surge Protective Devices
|
| Voltage Rating |
240
|
