Panduit Panduit LCB1-38-E

Name: Panduit LCB1-38-E
Brand: Panduit
SKU: 2195939
Price: 13.29 USD
Availability: InStock

Panduit LCB1-38-E

Kirby Risk #: 2195939

UPC: 07498343269, 074983432691, 30074983432692, 00074983432691

Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)

Brand: Panduit

Description

Industry Description

One-hole, long barrel lug, #1 AWG wire, 3/8 stud hole, standard package.

Modified Industry Description

1 AWG 3/8 IN 1 HOLE LONG BARREL CU COMP LUG

AD Description

Panduit® Pan-Lug™ LCB1-38-E 1-Hole Compression Lug, 1 AWG Stranded Copper Conductor, Die Code: P37, 3/8 in Stud, Copper

Brand Name	Panduit
Color	Green
Conductor Material	Copper
Conductor Size	1
Country of Origin	MEX
Material	Copper
Mounting	1 7/16
Number_Of_Holes	1
Package_Quantity	1
Size	#1 Code
Special Features	Color coded barrels marked with Panduit® and specified competitor die index numbers for proper crimp die selection Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V Enclosed barrel prevents corrosive material from entering barrel when used in harsh environments Long barrel maximizes number of crimps and provides premium wire pull-out strength and electrical performance Tin plated to inhibit corrosion
Standard	C22.2 No. 65-13, 486A-486B File #E52164
Stud_Size	3/8
Sub_Brand	Panduit
Temperature_Rating	90
Type	1-Hole
Voltage Rating	35
