Panduit Panduit LCDX250-38-X
Panduit LCDX250-38-X
Kirby Risk #: 2184181
UPC: 07498342401, 074983424016, 30074983424017, 00074983424016
Localizer[LocalizerResources.ManufacturerPartNumber].Value + ":") modelSummary.ManufacturerPartNumber)
Brand: Panduit
Description
Industry Description
Two-hole, flex lug, 250 kcmil cable, 3/8 stud hole, 1.75 hole spacing.
Modified Industry Description
Copper Compression Lug, 2 Hole, 250
AD Description
Panduit® Pan-Lug™ LCDX250-38-X 2-Hole Lug Compression Connector With Window Lug, 250 kcmil/262.6 kcmil, Die Code: P62, 3/8 in Stud, Tin Plated Copper
Specifications
| Brand Name |
Panduit
|
|---|---|
| Color |
Yellow
|
| Conductor Material |
Copper
|
| Conductor Size |
250
|
| Country of Origin |
MEX
|
| Material |
Tin-Plated Copper
|
| Mounting |
1 1/16
|
| Number_Of_Holes |
2
|
| Package_Quantity |
1
|
| Size |
250 kcmil Class G, H, I, K, M and 262.6 kcmil DLO
|
| Special Features |
Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
|
| Standard |
CSA certified C22.2 No. 65-13, UL Listed to 486A-486B File #E52164, ABS approved
|
| Stud_Size |
3/8
|
| Sub_Brand |
Panduit
|
| Type |
Type LCDX
|
| Voltage Rating |
35k
|
