Amprobe Amprobe 5XP-A


Description

Industry Description

This Amprobe Digital Multimeter provides superior features and accuracy in a smaller form factor. This Digital Multimeter has unique features such as VolTect™ non-contact voltage detection and our exclusive Magne-Grip™ holster that frees both hands for work. This is the perfect choice for residential, commercial and general troubleshooting applications.

Modified Industry Description

COMPACT DMM WITH NON-CONTACT

AD Description

Amprobe® 5XP-A AC/DC Compact Digital Multimeter With VolTect™, 2 to 600 VAC/VDC, 200 mVAC/mVDC, 200 uA, 2 to 200 mA, 200 Ohm, 2 to 200 kOhm, 2 to 20 MOhm, 3-1/2 Digits 1999 Counts LCD Display

Vendor Description

The Amprobe® 5XP-A digital multimeter provides superior features and accuracy in a smaller form factor. The 5XP-A has unique features such as VolTect™ non-contact voltage detection and our exclusive Magne-Grip™ holster that frees both hands for work. The 5XP-A is the perfect choice for residential, commercial and general troubleshooting applications.

Specifications

Amperage Rating
200µ/20m/200m/2
Application
Full-purpose multimeter for residential, commercial and general troubleshooting applications
Country of Origin
TW
Dimensions
6.1 x 2.83 x 1.26
Display
3-1/2 digit liquid crystal display (LCD) with a maximum reading of 1999
Enclosure
Hard Plastic
Length1
10.2400
Material
Plastic
Special Features

  • +/-1% RDG + 4 digits at 200 Ohm and 2 to 200 kOhm, +/-1.5% RDG + 4 digits at 2 MOhm, +/-2% RDG + 5 digits at 20 MOhm resistance accuracy
  • +/-1.5% RDG + 1 digit DC current accuracy
  • +/-2% RDG + 5 digits AC current accuracy
  • 27 ranges/10 functions
  • Battery load test with 1.5 VDC and 9 VDC capabilities
  • Data hold
  • Low battery indication
  • Maximum/minimum record maximum and minimum values
  • VolTect™ non-contact voltage (NVC) detection
Standard
Conform to EN610101,Rev-2; CAT I 1000 V,CAT II 600 V, CAT III 300, V(5XP-A,35XP-A), CAT II 1000 V, CAT III 600 V(15XP-B), class 2 and pollution deg.2; CSA 22.2 -1010-1
Sub_Brand
Amprobe
Temperature_Rating
0 to 50
Type
Digital Multimeter
Voltage Rating
200m/2/20/200/750//200m/2/20/200/1k
